Hitachi Floor Ceiling Air Conditioners RPFC-3.0 UNZ1NH / RAS-3.0UNZGNH1 2 Ton (Heat & Cool)

Specifications of LG Split Air Conditioner 1.0 Ton I12CGH DUALCOOL Inverter

• Dual Inverter Compressor™
• TUV Rheinland
• Energy Saving
• Fast Cooling

Cooling – Min ~ Rated ~ Max(kW): 0.88/3.52/3.87
Cooling – Min ~ Rated ~ Max(Btu/h): 3,000/12,000/13,200
Heating – Min ~ Rated ~ Max(kW): 0.88/3.52/4.04
Heating – Min ~ Rated ~ Max(Btu/h): 3,000/12,000/13,800
Cooling – Min ~ Rated ~ Max(W): 140/1,085/1,400
Heating – Min ~ Rated ~ Max(W): 140/975/1,550
Cooling – Min ~ Rated ~ Max(A): 0.70/5.00/6.50
Heating – Min ~ Rated ~ Max(A): 0.70/4.80/7.50
EER(W/W): 3.24
EER((Btu/h)/W): 11.06
COP(W/W): 3.61
COP((Btu/h)/W): 12.31
POWER SUPPLY: Ø, V, Hz: 1, 220 ~ 240, 50
Available Voltage Range(V): 187 ~ 276
Cooling/Heating(%): 94/94
Moisture Removal(l/h): 0.80
Air Flow Rate – Cooling, Max/H/M/L(m³/min): 12.5/9.3/7.2/2.7
Air Flow Rate – Heating, Max/H/M/L(m³/min): 13/10/7/5.5
Sound Pressure Level – Cooling, H/M/L/SL(dB(A)): 42/36/28/21
Sound Pressure Level – Heating, H/M/L(dB(A)): 42/36/31
Dimensions (W×H×D) – Net(mm): 837 × 308 × 189
Dimensions (W×H×D) – Shipping(mm): 909 × 383 × 256
Weight – Net(kg): 8.5
Weight – Shipping(kg): 10.6
Munsell: 7.5BG 10/2 (RAL 9016)
Air Flow Rate – Max(㎥/min): 27.0
Sound Pressure Level – Cooling, Rated(dB(A)): 51
Sound Pressure Level – Heating, Rated(dB(A)): 53
Dimensions (W×H×D) – Net(mm): 717 × 483 × 230
Dimensions (W×H×D) – Shipping(mm): 837 × 530.5 × 332
Weight – Net(kg): 26.4
Weight – Shipping(kg): 30.1
Max. Fuse Size(A): 20
Munsell 9.54Y 8.34/1.31 (RAL 9001)
Operation Range – Cooling(℃ DB): 18 ~ 48
Operation Range – Heating(°C DB): -5 ~ 24
Operation Range – Heating(℃ WB): -5 ~ 18
Circuit Breaker(A): 15
Power Supply Cable(No.×㎟): 3 × 1
Power and Communication Cable(No.×mm²): 4 × 0.75
PIPING Size – Liquid(mm): Ø 6.35
Size – Gas(mm): Ø 9.52
Connections Method – Indoor/Outdoor
Flared/Flared
DRAIN HOSE SIZE
O.D, I.D(mm): 21.5, 16.0
BETWEEN INDOOR & OUTDOOR
Piping Length – Min/Standard/Max(m): 3.6/7.5/15
Piping Length – No Charge(m): 7.5
Max. Elevation Difference(m): 7
Piping Connection Heat Insulation
Both liquid and Gas Pipes
REFRIGERANT
Type: R410A
Pre Charge(g): 850
Additional Charge(g/m): 20
Control: Capillary
Global Warning Potential: 2087.5
t-CO₂ eq: 1.774
DEFROST METHOD
Defrost Method: Reverse Cycle:
Indoor/Outdoor: SJ/UA3
COMPRESSOR
Type: Twin Rotary
Oil Type/Maker: POE (RB68A)/Sun Oil or Jx Nippon
Oil Charge(cc): 280
FAN(INDOOR) Type: Cross Flow Fan
Motor Output (W): 30
FAN(OUTDOOR): Type
Propeller Fan Motor Type: AC
Motor Output(W): 25
Motor Insulation: Class E
Motor Enclosure/Ingress Protection: TEAO/IP43
HEAT EXCHANGER
Evaporator – Material, Tube/Fin: Cu/Al
Evaporator – (ø x Row x Column x FPI x L) x Qty.(#1)
(ø7 x 2 x 16 x 20 x 744) x 1
Evaporator – Corrosion Protection: PCM
Evaporator – Fin Type: Slit
Condenser – Material, Tube/Fin: Cu/Al
Condenser – (ø x Row x Column x FPI x L) x Qty.(#1): (ø7 x 2 x 22 x 18 x 667) x 1
Condenser – Corrosion Protection: Gold
Condenser – Fin Type: Louverk
